Basal Ganglia Disorders Associated with Imbalances in the Striatal Striosome and Matrix Compartments

Development of the striosome and matrix compartments

A striosome-substantia nigra-striatum circuit is established relatively early in the developing striatum. The striosomal neurons are born in a discrete time-window, during the time that layer 6 neurons of the neocortex are born (Graybiel and Hickey, 1982), as though forming an ontogenetic unit. They begin to migrate out from the lateral ganglionic eminence earlier in development than most matrix neurons, which are mainly born later in embryogenesis. The developing striosomes correspond to the “dopamine islands” formed by incoming dopamine-containing nigrostriatal fibers (Olson et al., 1972; Graybiel, 1984; Moon Edley and Herkenham, 1984; Fishell and Van Der Kooy, 1987). Anatomical studies suggest that the clusters of MSNs in the proto-striosomes begin to mature just in advance of the dopamine-containing fibers that demarcate the clusters (Newman-Gage and Graybiel, 1988). The dopamine-containing fiber input to striosomes is nevertheless required for the expression of some striosomal markers, including the mu opioid receptor (Van Der Kooy and Fishell, 1992).

The protostriosomal neurons project to developing dopamine-containing neurons in the ventral mesencephalon and secrete Reelin (Nishikawa et al., 1999), a protein that is essential for the lateral migration of dopamine-containing neurons that come to form the SNc (Nishikawa et al., 2003). The neurotrophic factor, GDNF, is also enriched in striosomes, and its expression in the striatum is important for survival of the dopamine-containing neurons (Lopez-Martin et al., 1999; Oo et al., 2005). As later-born matrix neurons migrate out into the striatum, they form caudal-to-rostral and lateral-to-medial gradients of migration, beginning around E20 in rats (Liu and Graybiel, 1992) and at comparable times in cats (Newman-Gage and Graybiel, 1988). Peri-natally, cell-type specific expression of ephrins and their receptors serve to compartmentalize the MSNs into striosome and matrix compartments (Janis et al., 1999; Passante et al., 2008). Finally, extracellular matrix proteins and peri-neuronal nets have dynamic compartmental distributions that may contribute to the consolidation of synaptic circuits and the mature appearance of the striatum by about P20 (Liu and Graybiel, 1992; Lee et al., 2008).

In adulthood, striosomes make up roughly 15% of the volume in the dorsal striatum (Johnston et al., 1990) of humans, monkeys, rats, and mice and they are largest in the rostral and medial parts of the striatum – to be precise, the medial and anterior caudoputamen in rodents and the caudate nucleus and anterior putamen in primates (Graybiel and Ragsdale, 1978). Striosome–matrix compartmentalization is largely, but not entirely, observed by the dendrite and local axon collaterals of striatal neurons. MSNs have axon collaterals that mainly synapse onto neighboring MSNs within the same compartment, and the dendritic trees of MSNs tend to be compartmentally confined (Walker et al., 1993; Kincaid and Wilson, 1996; Yung et al., 1996; Fujiyama et al., 2011). It is thought that differential activation of striosomes and matrix could be modulated, in part, by differentially distributed striatal interneurons, including cholinergic interneurons and somatostatin/nitric oxide synthase-positive interneurons that tend to be located at compartment borders (Graybiel et al., 1986; Kubota and Kawaguchi, 1993; Aosaki et al., 1994; Saka et al., 2002; Miura et al., 2007).

A number of transcription factors, including Ctip2 (Arlotta et al., 2008), RARβ (Liao et al., 2008), and Dlx1/2 (Anderson et al., 1997) are required for the differentiation of MSNs. The compartment-enriched expression of multiple genes has been found to change not only prenatally, but also during the period between birth and maturity, as the compartmental pattern matures. Remarkably, despite the limitation of anatomical marking of post-mortem human brain sections, evidence suggests that the outlines of this developmental pattern are visible in humans. Striosomes have been identified in prenatal striatum by histochemical (acetylcholinesterase) staining methods and a switch in the compartmental staining with this marker occurs during the postnatal period (Graybiel and Ragsdale, 1980). There are also cross-species variations in compartmental gene enrichment. Table 1 summarizes molecules reported to be differentially expressed in striosomes or extra-striosomal matrix, with a bias toward differences reported in adult animals.

Common and distinct efferent connections of the striosome and matrix compartments

Definitive evidence about the connections of striosomal MSNs has been difficult to obtain for technical reasons, but a recent study based on single-neuron labeling now suggests that in adult rats, striosomal MSNs may be unique among striatal MSNs in projecting directly to the SNc, which contains dopamine-producing neurons (Fujiyama et al., 2011). This single-neuron evidence is in accord with earlier work with classical anterograde and retrograde tracing methods (Gerfen, 1985; Jimenez-Castellanos and Graybiel, 1989; Tokuno et al., 2002). One such retrograde labeling experiment indicated that the densocellular zone of the SNc, which exhibits low levels of acetylcholinesterase (AchE) immunoreactivity relative to the surrounding region, is preferentially targeted by striosomes, which are also AchE-poor (Jimenez-Castellanos and Graybiel, 1989). In the rat, the striatonigral fibers have been suggested to form symmetric synapses on both the dendrites and cell bodies of the dopamine-containing neurons (Somogyi et al., 1981; Gerfen, 1984; Tokuno et al., 2002; Fujiyama et al., 2011). A monosynaptic connection between MSNs and dopamine-producing cells of the SNc is also consistent with electrophysiological recording assays in rats (Lee and Tepper, 2009). If confirmed by further work, the direct striosome-SNc projection would parallel a ventral striatal input to the SNc (Somogyi et al., 1981). The striosomes and ventral striatum are in a position to exert global control over dopamine signaling in the dorsal striatum.

Aside from this connection, both striosomes and matrix share in projecting to the main output nuclei of the basal ganglia, but in different proportions. These projections are more abundant from the large matrix compartment (Gerfen and Young, 1988; Jimenez-Castellanos and Graybiel, 1989; Rajakumar et al., 1993; Tokuno et al., 2002; Levesque and Parent, 2005; Fujiyama et al., 2011). Efferents from MSNs in the matrix have consistently been found not to project to the SNc but, rather, to project to the GPe, GPi, and SNr (Gerfen, 1984; Kawaguchi et al., 1990; Gimenez-Amaya and Graybiel, 1991; Levesque and Parent, 2005; Chuhma et al., 2011; Fujiyama et al., 2011). Likewise, a juxtacellular labeling experiment identified six MSNs, all located within the same striosome in the striatum of a squirrel monkey, that had projections to the GPi, GPe, and non-dopaminergic SNr, rather than to the dopamine-containing SNc (Levesque and Parent, 2005). Striosomal MSNs targeting the GPi, GPe, and SNr have also been reported in the rat. Striosomal MSNs that target the GPi/EP are reported to innervate specifically the regions of the GPi that in turn project to the lateral habenula, whereas the matrix MSNs targeting GPi/EP project to regions that are interconnected to motor regions of the thalamus (Rajakumar et al., 1993). This pathway to the habenula is notable, because the lateral habenula, itself interconnected with the prelimbic cortex, can inhibit dopamine cell firing in the SNc (Herkenham and Nauta, 1979; Christoph et al., 1986; Ji and Shepard, 2007; Matsumoto and Hikosaka, 2007; Bromberg-Martin et al., 2010). Thus, the striosomes appear to represent a unique dopamine- and limbic system-related circuit that is situated to influence the associative and sensorimotor regions of the striatum.

Based on these findings, a three-compartment model of striatal efferent connectivity has been proposed, including: (1) the direct pathway targeting the SNr with collaterals in the GPi/EP and GPe, (2) the indirect pathway targeting only the GPe, and (3) the striosome-specific pathway targeting the SNc, with collaterals in the GPi/EP and GPe (Figure 1B; Graybiel et al., 2000; Fujiyama et al., 2011). The apparently unique projection of striosomes to the SNc, if confirmed, would place striosomes in a functionally pivotal position to influence the dopamine system of the midbrain.

Relationship between the direct–indirect pathway divisions and striosome–matrix compartments

MSNs can be classified according to whether they give rise to either the direct or indirect pathways, and they can also be classified according to whether they are in striosomes or in the extra-striosomal matrix. These are two distinct classificatory schemes. Most of the neurons of direct and indirect pathways lie in the matrix, which makes up approximately 80% of the volume of the striatum. There is evidence that some neurons in striosomes project to direct pathway targets, and others (fewer in number) project to indirect pathway target nuclei. Single-fiber tracing methods have allowed definitive identification of the collaterals of efferent axons of neurons identified as belonging to either striosomes or matrix. Fujiyama et al. (2011) labeled 11 striosomal neurons that were distributed across the striatum and in different rats, and found that 8 projected to the SNc, with collaterals in one or more of the direct pathway targets (SNr, GPi/EP, and GPe) and 3 exhibited an indirect pathway projection pattern, solely to the GPe. Similarly, in the monkey labeling experiment by Parent and colleagues, all six of the labeled striosomal neurons projected to the direct pathway nuclei (Levesque and Parent, 2005). Thus, at least some striosomes have an overabundance of neurons that target GPi/EP and SNr, but they may target specific regions of these nuclei, relative to matrix MSNs. In the matrix, as a whole, the MSNs are equally divided between the direct and indirect pathway projection types. MSNs that target the SNc appear to be restricted to the striosomes and are not found in the matrix.

Direct and indirect pathway MSNs are often identified by their expression of peptides in addition to their expression of dopamine receptors. Direct pathway D1-positive MSNs express substance P and prodynorphin, whereas the indirect pathway D2-positive MSNs express proenkephalin/enkephalin (Gerfen and Young, 1988). In adult rats, an estimated 5% of MSNs in the dorsal striatum express both D1/substance P and D2/enkephalin, whereas co-expression in the ventral striatum may be slightly higher (Surmeier et al., 1996; Wang et al., 2006a; Bertran-Gonzalez et al., 2008; Perreault et al., 2010). D1/D2 heteromers have been discovered and are thought to signal through phospholipase C, a calcium-dependent signaling cascade, rather than through the canonical adenylyl cyclase, cAMP-dependent dopamine receptor signaling cascade (Lee et al., 2004; Perreault et al., 2010). Neurons that co-express substance P and enkephalin have been found in both striosomes and matrix, but may represent a greater proportion of the MSNs in the striosomal compartment than in the matrix (Besson et al., 1990; Wang et al., 2007). Furthermore, co-expression of substance P and enkephalin was abundant in terminals in the SNc, but not in the GPe, GPi, or SNr (Wang et al., 2006a). Thus, it is possible that some of the unique subset of striosomal neurons that target the SNc co-express D1 and D2. This would stand in contrast to the direct pathway neurons of the matrix, which express primarily D1. However, the expression profiles of the striosome-specific pathway MSNs, which target the SNc, have not yet been thoroughly analyzed. Such analysis should take into account that the expression levels of the proteins that are typically used to define the pathways and compartments, including prodynorphin, mu opioid receptor, and dopamine receptors, can change with experience (Moratalla et al., 1996; Cenci et al., 1998; Adams et al., 2003; Jabourian et al., 2005; Perreault et al., 2010).

In summary, data support a model in which MSNs projecting to the SNc are confined to striosomes (striosome-specific pathway), whereas MSNs contributing to the direct and indirect pathway are present mainly in the matrix compartment but also in striosomes. The direct and indirect pathway target nuclei (GPi, SNr, and GPe/EP) receive more inputs from MSNs in the matrix than those in striosomes, because the matrix compartment is much larger than the striosomal compartment. The balance of signaling between the direct and indirect pathways is strongly influenced by dopamine and, therefore, striosomal MSNs are in a position to control this balance through their projection to the dopamine-containing neurons of the SNc. Cholinergic interneurons, which are often located at the border between striosomes and matrix, can also control dopamine release (Threlfell and Cragg, 2011) and the balance of direct vs. indirect pathway activation (Ding et al., 2011).

Amemori et al. (2011) propose a model whereby striosomes and indirect pathway MSNs select modules of previously learned behaviors that are appropriate for the given environmental context. In this model, the direct pathway selects specific actions within each striatal module, whereas the indirect pathway serves to select among modules. Based on contextual prediction errors originating in the limbic system, striosomes provide “responsibility signals” that regulate the activity of adjacent matrix MSNs within their respective modules. This modular regulation is amplified through the indirect pathway by virtue of funneling of representations, which serves to select modules (rather than specific actions) based on contextual information. This model is supported by computational modeling experiments and would support context-dependent learning and faster behavioral adaptation in a fluctuating environment.

Cerebral cortex afferents to striosome and matrix compartments

Although a majority of neocortical areas may project to both striosomes and matrix, there are major differences in the strength of the projections to the two compartments. In keeping with the concept that ontogeny recapitulates phylogeny, striosomal MSNs not only begin differentiating before matrix MSNs, but also are innervated by neurons in more evolutionarily conserved regions of the cerebral cortex, especially the limbic medial and lateral margins of the cortical plate (Ragsdale and Graybiel, 1988; Gerfen, 1989). The orbitofrontal, anterior cingulate, and insular cortices preferentially innervate striosomes, whereas projections from the somatosensory, motor, and association cortices terminate mainly in the matrix (Ragsdale and Graybiel, 1990; Flaherty and Graybiel, 1994; Eblen and Graybiel, 1995; Kincaid and Wilson, 1996; Levesque and Parent, 1998). The amygdala, hippocampus, and nucleus accumbens (part of the ventral striatum) are interconnected with the orbitofrontal, anterior cingulate, and insular cortices, supporting the idea that the striosomes are part of a limbic circuit embedded in the sensorimotor and associative striatum (Graybiel, 2008). Indeed, in the cat, part of the amygdala itself also projects to part of the striosomal system (Ragsdale and Graybiel, 1988).

The strong innervation of medial striosomes by limbic neocortical regions that have reduced superficial layers is consistent with the fact that striosomal MSNs receive preferential inputs from deep cortical layer Vb (Gerfen, 1989; Eblen and Graybiel, 1995; Kincaid and Wilson, 1996; Levesque and Parent, 1998). MSNs in the matrix receive input from ontogenically younger, and putatively evolutionarily younger, cortical layers (III–Va). This is consistent with the finding that the somatosensory cortex, which is part of the neocortex that has a well-defined upper layer Va, projects to the matrix and not to the striosomes (Wilson, 1987; Gerfen, 1989). Nevertheless, the correlation between evolutionary age and compartment-specific targeting of corticostriatal neurons is speculative and does not fully represent the types of compartmentalized targeting that have been observed. For example, labeling of efferents from individual cortical regions was found to preferentially fill striosomes dorsally but to avoid striosomes ventrally, within their striatal target zones (Ragsdale and Graybiel, 1990). The striatal target zones themselves progressed dorso-ventrally according to the neighboring cortical regions from which they arose and thus, neighboring striosome–matrix compartments received input from neighboring cortical regions.

Corticostriatal projection neurons send efferents to other brain regions, including the brainstem, thalamus, claustrum, and contralateral cortex (Wilson, 1987; Kincaid and Wilson, 1996; Levesque et al., 1996). Upper layer V is enriched in intra-telencephalic-projecting (IT-type) neurons that can bifurcate to both hemispheres and synapse preferentially onto D1-positive MSNs. By contrast, deep layer V is enriched in pyramidal tract-projecting (PT-type) neurons that send collaterals preferentially to D2-positive MSNs in the ipsilateral striatum (Reiner et al., 2003). Axon terminals from PT-type cortical neurons were found to be larger and more often contacted a perforated post-synaptic density, compared to the IT-type corticostriatal terminals that contacted direct pathway MSNs (Reiner et al., 2010). This is consistent with the preferential activation of IEGs in enkephalin-containing neurons found in response to activation of the motor cortex (Berretta et al., 1997; Parthasarathy and Graybiel, 1997). Based on evidence that afferents to striosomes arise preferentially from deep layers of limbic cortex, one might expect striosomes to receive preferential PT-type inputs. However, the properties of corticostriatal synapses, such as terminal area and post-synaptic density length, were found to be similarly distributed between striosomes and matrix (Fujiyama et al., 2006) and both IT-type and PT-type projections have been detected in striosomes (Donoghue and Herkenham, 1986; Levesque and Parent, 1998; Wang and Pickel, 1998). These findings, together with the evidence that striosomes and matrix both have D1- and D2-dopamine receptor-expressing MSNs, even if not in equal proportion, indicate that each compartment receives input from both IT-type and PT-type cortical neurons. Reiner et al. (2010) point out that BAC mice expressing EGFP in either the PT neurons or the IT neurons will help to resolve this issue of whether there is preferential compartment targeting of one projection type.

In summary, each striatal compartment receives preferential inputs from different cortical regions and individual corticostriatal axons tend to innervate MSNs that are confined to a single compartment (Kincaid and Wilson, 1996). Nevertheless, subregions of the striatum that encompass both striosomes and neighboring clusters of cells in the matrix (matrisomes) are innervated by related cortical regions (Ragsdale and Graybiel, 1990; Flaherty and Graybiel, 1995; Kincaid and Wilson, 1996). Thus, MSNs in striosomes and matrisomes are thought to process related information and to communicate selectively with surrounding regions, likely via interneurons that have dendrites that cross compartmental borders. Such striatal interneurons include NOS/somatostatin-positive interneurons and parvalbumin-positive interneurons, which receive strong input from the cerebral cortex, and cholinergic interneurons, which receive strong input from the thalamus (Graybiel et al., 1986; Sandell et al., 1986; Lapper and Bolam, 1992; Lapper et al., 1992; Kubota and Kawaguchi, 1993; Bennett and Bolam, 1994; Aosaki et al., 1995; Kawaguchi, 1997; Saka et al., 2002; Miura et al., 2008).

Thalamic and nigral afferents to striosome and matrix compartments

Thalamic and cortical neurons make excitatory, asymmetric synaptic connections onto MSNs in similar proportions (Doig et al., 2010). These inputs can be distinguished by immunostaining for the vesicular glutamate transporters VGluT1 (present in cortical terminals and also in less abundant amygdaloid terminals) and VGluT2 (present in thalamic terminals), according to evidence from numerous laboratories (Fremeau et al., 2001; Lacey et al., 2005; Raju et al., 2006). With these markers, it was found that inputs from the thalamus terminate on both dendritic spines and dendritic shafts of striatal neurons (Lacey et al., 2005; Raju et al., 2006), but the inputs to shafts are largely confined to the matrix (Fujiyama et al., 2006; Raju et al., 2006). This compartmental selectivity is likely due to the fact that inputs from the parafascicular nucleus, one of the intralaminar nuclei of the thalamus, terminate onto the shafts of cholinergic interneurons (Lapper and Bolam, 1992), which are abundant in the striatal matrix. The parafascicular inputs also contact spines and shafts of MSNs (Lacey et al., 2007). The intralaminar thalamic nuclei are highly interconnected with sensorimotor cortical regions and preferentially target the matrix (Herkenham and Pert, 1981; Ragsdale and Graybiel, 1991; Sadikot et al., 1992). By contrast, the midline paraventricular and rhomboid nuclei of the thalamus, which have strong connections with the nucleus accumbens and the amygdala, have been shown in the cat to target striosomes preferentially (Ragsdale and Graybiel, 1991). This pattern is consistent with striosomes participating in cortico-striato-thalamic circuits with limbic connections and the extra-striosomal matrix participating in cortico-striato-thalamic circuits with sensorimotor connections.

Striosomes and matrix receive dopamine-containing inputs preferentially from distinct groups of neurons in the SNc. The distinct localization of the striosome vs. matrix targeting nigrostriatal neurons has been better documented in rats than in primates (Joel and Weiner, 2000), but differences have been documented in multiple species. The striosomal MSNs are innervated by a group of densely packed dopamine-containing neurons in the ventral tier of the SNc (the A9 cell group) and groups of clustered dopamine-containing neurons that are intermingled with neurons of the SNr (densocellular zone; Gerfen et al., 1987; Jimenez-Castellanos and Graybiel, 1987; Langer and Graybiel, 1989; Prensa and Parent, 2001). These results suggested that there may be reciprocal connections between some of the striosomal system, at least of the so-called subcallosal streak in the lateral striatum, and the densocellular zone of the SNc (Jimenez-Castellanos and Graybiel, 1989; Prensa and Parent, 2001). Matrix neurons are preferentially innervated by dopaminergic neurons in the dorsal tier of the SNc, the retrorubral area (A8 cell group) and the ventral tegmental area (VTA; A10 cell group; Gerfen et al., 1987; Jimenez-Castellanos and Graybiel, 1987; Prensa and Parent, 2001). Nevertheless, single dopamine-containing fibers can innervate both striosomes and matrix (Matsuda et al., 2009) and, for example, ventral tier SNc neurons are reported to innervate the matrix surrounding a target striosome (Prensa and Parent, 2001). The dopamine-containing axons innervating striosomes are reported to be thicker and to have more varicosities than those innervating the matrix, even when the axons are simply different branches from the same innervating neuron (Gerfen et al., 1987; Prensa and Parent, 2001). The ultrastructure of the dopamine-containing afferents is equivalent between compartments, however, and situated so as to modulate both cortical and thalamic excitatory inputs to MSNs (Hanley and Bolam, 1997; Moss and Bolam, 2008). In addition to this compartmental organization of the nigrostriatal system is the well-known gradient of dopamine-containing inputs whereby the medial VTA projects to the ventral striatum and the SNc, located more laterally, projects to the dorsal striatum.

Huntington’s disease

Huntington’s disease is a fatal neurodegenerative disease caused by an expanded CAG repeat in the IT15 gene for Huntingtin protein (Htt; The Huntington’s Disease Collaborative Research Group, 1993). The CAG expansion encodes a polyglutamine tract that contributes to aggregation of the mutant Htt. HD is typified by the death of striatal MSNs and neocortical neurons and by symptoms of emotional disturbances and uncontrollable, choreic motor movements (Bates et al., 2002). HD hyper-kinesia may be linked in part to the preferential degeneration of D2 dopamine receptor-expressing MSNs of the indirect pathway, which normally inhibit movement (Reiner et al., 1988; Delong, 1990; Glass et al., 2000). Experiments regarding selective vulnerability of either striosome or matrix compartments have yielded variable results, however (Table 2).

Early reports indicated that tissue from individuals with early-stage HD have more severe loss of neurons and immunomarkers in the striosomes than in the matrix, whereas tissue from late-stage cases have equivalent neurodegeneration between compartments (Morton et al., 1993; Hedreen and Folstein, 1995). In mouse models, in which death of MSNs is minimal but neurite pathology is evident, there is more Htt aggregate burden and preferential volume loss in striosomes, relative to matrix (Menalled et al., 2002; Lawhorn et al., 2008). These patterns are not universal across individuals or models, and other clinical studies even found preferential loss of matrix markers (Ferrante et al., 1987; Seto-Ohshima et al., 1988). Some clarity to this controversy was provided by a study of 35 HD cases correlating symptomatology and compartmental-specific cell loss analyzed in post-mortem specimens (Tippett et al., 2007). In this study, reduced cell density in striosomes is more frequently observed in striatal sections from the brains of individuals who had presented early on with mood, rather than motor, symptoms. The emotional symptoms in the HD cases included depression, anxiety, and compulsively repetitive behaviors. Furthermore, in a follow-up study, it was shown that cell loss in the anterior cingulate cortex is more severe in post-mortem tissue samples from the individuals that presented with primarily emotional symptoms (Thu et al., 2010). Thus, neurodegeneration of components of the striosome limbic loop is associated with the emotional symptoms that characterize HD. Considering that post-mortem analysis is typically restricted to late-stage HD when nearly the entire brain is affected, longitudinal imaging studies, including of pre-symptomatic individuals, are providing more insight into the correlations between the complex symptomatology and neuronal degeneration patterns that typify HD (Rosas et al., 2008; Politis et al., 2011).

Despite the wide-spread expression of the mutant isoform of Htt in HD, there is disproportionate cell death of striatal MSNs and cortical pyramidal neurons, relative to loss of local interneurons or to neuronal loss in other brain regions. HD leads to a large array of cellular changes, including oxidative stress responses, transcriptional dysregulation, and excitotoxicity. Excitotoxicity is thought to be evoked, at least in part, by an impaired capacity to buffer the calcium rise that follows the stimulation of glutamate and dopamine receptors (Beal, 1998; Bezprozvanny and Hayden, 2004; Tang et al., 2007). Accordingly, disruption of either the cortical (glutamatergic) or nigral (dopamine-containing) afferents to the striatum is protective in the R6/2 mouse model of HD (Stack et al., 2007). Neocortical stimulation, D1 dopamine receptor activation and D2 receptor antagonism can all activate striatal ERK1/2, which exhibits altered activation patterns in HD models (Lievens et al., 2002; Roze et al., 2008). ERK1/2 signaling leads to phosphorylation and activation of the transcription factors ELK1 and CREB (Figure 2) and, thereby, could contribute to, or compensate for, the massive transcriptional dysregulation that occurs in HD (Cha, 2007). Other relevant changes in transcription factors are not discussed here, but even wildtype Htt, as well as mutant Htt, can directly control transcription (Benn et al., 2008).

In view of evidence that there are striosome-predominant and matrix-predominant patterns of cell loss in individual cases of HD, it is of special interest that two striatum-enriched molecules that signal through ERK1/2, CalDAG-GEFI, and CalDAG-GEFII (Figure 2), have strongly compartmentalized patterns of expression. CalDAG-GEFII (aka RasGRP) is expressed especially in striosomes, and CalDAG-GEFI is expressed preferentially in the matrix compartment. The CalDAG-GEFs are severely down-regulated in the R6/2 mouse model of HD and in post-mortem striatal tissue from individuals with HD (Crittenden et al., 2010a,b). This down-regulation is not a function of the preferential loss of D2-positive neurons in HD, considering that CalDAG-GEFI and CalDAG-GEFII are expressed in both prodynorphin and preproenkephalin-positive striatal neurons (Toki et al., 2001). The CalDAG-GEFs contain calcium and diacylglycerol binding domains and signal to the ERK1/2 phosphorylation cascade (Kawasaki et al., 1998) following the activation of cell surface receptors (Dower et al., 2000; Guo et al., 2001; Crittenden et al., 2004). For CalDAG-GEFI, it is known from work in a cortical slice model of HD that knockdown of CalDAG-GEFI expression blocks at least some of the deleterious effects of over-expressing a mutant fragment of the Htt protein (Crittenden et al., 2010a). Thus, the down-regulation of CalDAG-GEFI that is observed in HD may be compensatory. The consequences of CalDAG-GEFII dysregulation in HD models still need to be evaluated. Interestingly, in contrast to CalDAG-GEFI, another matrix-enriched calcium-binding protein, calbindin-D28K, is up-regulated in HD and HD animal models, and this change has been suggested to be protective against calcium-induced excitotoxicity (Huang et al., 1995; Sun et al., 2005). Most striatum-enriched genes are down-regulated in HD however (Desplats et al., 2006), which may be a compensatory response to the differential vulnerability of the MSN cell-type to mutant Htt expression.

Parkinson’s disease and parkinsonism

Parkinsonian disorders are characterized by difficulty initiating movements, bradykinesia, muscle rigidity, and postural instability. Idiopathic PD is an age-related neurodegenerative disease second only to Alzheimer’s disease in prevalence. PD is typified by degeneration of dopamine-containing neurons in the SNc, which results in the loss of the dopamine-containing innervation of the striatum, usually with a progression of loss from posterior regions (putamen) that are important for the execution of voluntary movements toward anterior regions (caudate nucleus) that are more associative and limbic in function (Kish et al., 1988). PD is now thought to arise from an interaction between the environment and genetic susceptibility. Exposure to mitochondrial toxins, such as the pesticide rotenone or MPTP-tainted drugs of abuse, are well-documented risk factors (Shulman et al., 2011). A number of genetic mutations can lead to PD, including mutations in SNCA, which encodes alpha-synuclein and for which there is a gene dosage effect that correlates with the severity of disease (Singleton et al., 2003; Chartier-Harlin et al., 2004; Farrer et al., 2004). The pathologic SNc hallmark of PD has long been identified as the large cytoplasmic inclusions known as Lewy bodies, and these are highly enriched in alpha-synuclein protein.

Different groups of dopaminergic neurons within the SNc appear to have different vulnerability to cell death in PD. For example, the loss of neurons within the densely packed cell groups called nigrosomes correlates with disease duration, whereas dopamine-containing neurons in surrounding parts of the SNc are less vulnerable (Damier et al., 1999b). The “nigrosomes” of the substantia nigra share with the striosomes of the dorsal striatum the characteristic of being weakly immunoreactive for calbindin-D28k, relative to other nigral regions (Damier et al., 1999a). A study assessing neuronal loss in a single section through the caudal SNc of 20 PD cases and 36 control cases found preferential loss of pigmented cells in the ventro-lateral SNc in PD, relative to age-related loss of more dorsally located pigmented neurons in controls (Fearnley and Lees, 1991). A second study also reported increased vulnerability of neurons located in the ventro-lateral SNc that are calbindin-D28k-negative (Yamada et al., 1990), but this pattern is not uniform across studies and is likely dependent on the individual and how the SNc subregions are defined (Hirsch et al., 1988; Gibb, 1992). Direct measurements of differential striatal loss of dopamine-containing terminals in striosomes or matrix have not yet been possible because in nearly all PD cases that come to autopsy, the depletion of dopamine is so extensive that markers of the nigrostriatal innervation yield little or no signal.

Differential loss of dopamine terminals in the striosomes, relative to matrix, is observed in a mouse model of dopamine deficiency, weaver, which carries a mutation in the GIRK2/Kir3.2/KCNJ6 gene that encodes a G-protein-activated inwardly rectifying potassium channel (Graybiel et al., 1990c). However, systemic deficits in weaver mice, including in the cerebellum, preclude simple interpretation of motor effects from their striosomal dopamine deficiency. Overall, results from neurotoxin-induced dopamine depletion in animal models of PD have been mixed, with some reporting increased dopamine terminal loss from striosomes and others increased loss from matrix (Table 2). This inconsistency may be related to the fact that the site of intracerebral neurotoxin injection influences the pattern of compartment-selective terminal loss (Zahm, 1991). These studies are further confounded by the fact that the immunomarker typically used to label dopamine terminals, anti-tyrosine hydroxylase (TH) immunoserum, shows higher immunoreactivity in the matrix than in striosomes of normative animals in some species. This differential anti-TH immunoreactivity is observed prominently in primates, including in humans, and weakly in rodents (Graybiel et al., 1987). This mosaic pattern of TH immunostaining was found to be preserved in several post-mortem PD cases, but could only be assessed in the most ventral parts of the caudate nucleus and putamen that were not fully depleted of this marker (Graybiel et al., 1990a). Immunostains for the matrix or striosome MSNs themselves also show grossly normal mosaic staining patterns in striatal sections from individuals with idiopathic PD or in cases of parkinsonism-dementia complex of Guam (Ito et al., 1992, 1993).

In a rare form of parkinsonism, MSA-P, differential matrix vs. striosome MSN degeneration has been reported. In MSA-P, there is degeneration of multiple neuronal types, including MSNs and nigral neurons. Analysis of brain sections through the striatum obtained from individuals that died with MSA-P and control cases showed preferential loss of the matrix marker, calbindin-D28k, and maintenance of a striosome immunomarker in the individuals with MSA-P (Goto and Hirano, 1990; Ito et al., 1992; Sato et al., 2007). It was suggested that, in MSA-P, there is selective loss of matrix MSNs in early stages of disease that progresses to loss of MSNs in both compartments by late stages of disease (Sato et al., 2007). Early loss of matrix signaling in MSA-P is consistent with the course of dopamine terminal loss in more common forms of PD, in which terminal loss progresses forward from the caudal putamen, which is relatively poor in striosomes (Graybiel and Ragsdale, 1978).

Considering the heterogeneity of PD-related disorders, it is tempting to speculate that a consistent compartmentalized pattern of dopamine terminal degeneration might be found if patients were classified according to detailed symptomatology, as has been reported for HD (Tippett et al., 2007; Rosas et al., 2008; Thu et al., 2010). As we discuss in the following section, the best evidence to date for the status of striosomes and matrix in PD brains comes from work on the expression of preproenkephalin opioids in post-mortem sections from PD brains. In these, striosomes are clearly preserved and over-activated in the brains of patients who experienced dyskinesias as side effects of treatment (Henry et al., 2003).

L-DOPA-induced dyskinesias

The most widely available treatment for PD is dopamine replacement therapy by oral administration of the dopamine precursor, l-3,4-dihydroxyphenylalanine (l-DOPA). However, as the disease progresses and the dopamine depletion becomes increasingly more severe, l-DOPA treatment often produces debilitating involuntary movements referred to as LIDs. LIDs are likely evoked, at least in part, by hyper-responsivity of MSNs to pulsatile dopamine receptor stimulation during ongoing corticostriatal activation of glutamate receptors (Jenner, 2008). Thus, treatment for these side effects typically requires reducing the l-DOPA dosage to suboptimal levels.

In rodent and non-human primate models, the occurrence of LIDs is correlated with activation of both D1 and D2 dopamine receptors and hyperactivation of the pro-movement direct pathway (Gerfen et al., 1995, 2002, 2008; Jenner, 2008; Berthet et al., 2009; Meurers et al., 2009; Cenci and Konradi, 2010). Stimulation of D1 and glutamate receptors leads to the activation of two key protein kinase cascades, denoted by their central kinase mediators: PKA and ERK1/2 (Figure 2). D1 is known to signal through G-protein coupled receptors to activate adenylyl cyclase for the generation of cAMP. cAMP, in turn, activates PKA, which site-specifically phosphorylates the dopamine and cAMP-regulated phosphoprotein 32 kDa (DARPP-32). DARPP-32 intersects with the ERK1/2 cascade by blocking protein phosphatases that would normally deactivate ERK1/2 (Valjent et al., 2005; Santini et al., 2007). PKA and ERK1/2 control chromatin remodeling and phosphorylate the CREB and ELK transcription factors that converge to drive expression of numerous IEGs, including, for example, c-Fos (Valjent et al., 2005; Santini et al., 2007, 2009). The induction of numerous IEGs has been observed in D1-positive MSNs in normal animals treated with dopamine receptor agonists, and this induction is dramatically increased in the dopamine-depleted striatum of animals treated with l-DOPA (Valjent et al., 2005; Santini et al., 2007, 2009). Protein translation is also activated in D1-positive MSNs of animal models of LIDs, via activation of mammalian target of rapamycin (mTOR) and ERK1/2 (Santini et al., 2009). Several studies indicate that in models of LIDs, there is a switch from PKA- to ERK1/2-mediated signaling in driving IEG expression (Andersson et al., 2001; Gerfen et al., 2002). Nevertheless, inhibition of ERK1/2, PKA, or mTOR in the striatum attenuates the development of LIDs in animal models (Gerfen et al., 2002; Westin et al., 2007; Darmopil et al., 2009; Santini et al., 2009; Lebel et al., 2010). The wide-spread expression and functions of ERK1/2, PKA, and mTOR make them poor targets for therapeutic intervention, however. Evidence from IEG induction assays in human and animal models suggests that there is a striosome to matrix imbalance in signaling cascades that parallels the development of LIDs. Strikingly striosome-predominant increases in the expression of prodynorphin (also called preproenkephalin B) have been documented in post-mortem striatal sections from parkinsonian humans with LIDs (Henry et al., 2003). In monkeys, the IEG Nur77 is dysregulated in striosomes following dopamine depletion with and without dopamine replacement treatments (Mahmoudi et al., 2009). In the anterior caudate nucleus of monkeys with dopamine depletion only, Nur77 is down-regulated in striosomes, relative to levels in control monkeys. By contrast, following dopamine depletion with subsequent l-DOPA treatment, Nur77 is strongly up-regulated in striosomal neurons. The degree of Nur77 up-regulation is inversely correlated with the severity of the LIDs, suggesting that the Nur77 modulation is compensatory. Striosome-predominant IEG induction is also observed in the dopamine-depleted striatum, relative to control striatum, in rat models of LIDs (Cenci et al., 1999; Saka et al., 1999).

This heightened IEG activity in striosomes may be related to activation of the striosome-specific pathway to the SNc (Figure 1B) or to the predominance of D1-positive neurons in striosomes of some species, relative to matrix (Table 1). These possibilities have not been directly assessed, but gene induction studies show increased IEG expression in D1-positive neurons, relative to changes in D2-positive neurons, in rat models of LIDs (Gerfen, 2003; Santini et al., 2009; Bateup et al., 2010). Furthermore, there may be increased signal transduction from D1 receptors in striosomes in LIDs, considering that Gαolf, the G-protein that is coupled to the D1 receptor, is elevated in post-mortem tissue from individuals who died with a diagnosis of PD (Corvol et al., 2004). Gαolf is enriched in striosomes in normal mice (Sako et al., 2010). An imbalance in striosome to matrix activity may also be related to the finding that selective antagonists of mu opioid receptors dramatically reduce LIDs in non-human primate models (Koprich et al., 2011). Mu opioid receptor activation contributes to differential activation of striosomes over matrix (Miura et al., 2007), but whether mu opioid receptor antagonists reduce excessive striosome to matrix activity in LIDs has not yet been reported.

Increasing evidence suggests that ERK1/2-mediated IEG induction in LIDs may involve the striosome-enriched gene, CalDAG-GEFII (Kawasaki et al., 1998; Dower et al., 2000; Pierret et al., 2002; Crittenden et al., 2009). CalDAG-GEFII, an ERK1/2 activator, is strongly up-regulated in a rat model of LIDs, and has a striking striosome-enriched pattern. By contrast, the matrix-enriched gene, CalDAG-GEFI, is down-regulated in the same model. The dysregulation of both of these genes was found to occur in proportion to the severity of LIDs that were expressed premortem in rats (Crittenden et al., 2009). Genetic deletion of another ERK1/2 activator, Ras-GRF1, partially alleviates the development of LIDs in a mouse model, and combined Ras-GRF1 and ERK1/2 knockdown reduces LIDs in a monkey model (Fasano et al., 2010). LIDs are further reduced in the Ras-GRF1 knockout mice by treatment with doses of ERK1/2 antagonists that are too low to be effective in control mice. These results suggest that there are multiple pathways to ERK1/2 activation in LIDs and that Ras-GRF1 and CalDAG-GEFII might, together, fully activate this pathway.

Recent studies highlight evidence that ERK1/2 activation in MSNs is high in the early stages of LIDs induction but decreases with prolonged treatment, despite the maintenance of the dyskinetic behaviors (Santini et al., 2010; Ding et al., 2011). By contrast, striatal DARPP-32 phosphorylation is highest in dopamine-depleted animals that received prolonged l-DOPA treatment. These results led to the proposal that ERK1/2 cascades are important for the priming that constitutes excessive responses of dopamine-depleted animals to the first-ever l-DOPA treatment, whereas cAMP/PKA/DARPP-32 signaling cascades are important for the maintenance of LIDs. However, activated ERK1/2 has been found in cholinergic interneurons of parkinsonian rodent models after prolonged l-DOPA treatment, indicating that ERK1/2 may be critical in MSNs for LID priming and in a sparsely distributed striatal interneuron for LID maintenance (Ding et al., 2011).

Taken together, this evidence strongly suggests that MSNs in striosomes are over-activated, relative to matrix MSNs, in LIDs. This differential activation is likely related to PKA and ERK1/2 activation in striatal MSNs (likely involving the CalDAG-GEFs and Ras-GRF1), and in striatal cholinergic interneurons. Strikingly, increased IEG activation of striosomes relative to matrix is also evoked by over-stimulation of the dopamine system with drugs of abuse. Such over-stimulation elicits repetitive motor and cognitive behaviors that share features with LIDs that are observed in a subpopulation of individuals with PD (Voon et al., 2009). There is a strong and direct correlation between the severity of repetitive behaviors induced by dopamine receptor agonists and the ratio of striosome to matrix IEG up-regulation, further suggesting a link between these different hyper-kinetic states (Canales and Graybiel, 2000; Graybiel et al., 2000).

Dystonia

Dystonia presents as twisting limb movements or sustained abnormal body postures that are attributed to failures in motor control and sensory integration by the cortico-basal ganglia-thalamic loop (Kaji et al., 2005). Electromyographic recordings from the muscles of patients with dystonia have shown that, during a dystonic event, there is co-contraction of opposing muscles or activation of muscle groups neighboring those that are normally used (Cohen and Hallett, 1988; Fahn, 1989). Dystonia can appear in childhood or in adulthood and can involve a single body part (focal), a group of adjacent body parts (segmental) or the whole body (generalized). As with PD, the susceptibility to disease genes and risk factors is variable (Roze et al., 2009; Schmidt et al., 2009). Dystonia can be evoked by a wide variety of phenomena, including repetitive motor tasks, anti-psychotic medications, brain damage, environmental factors, neurological disease (e.g., PD and HD) and genetic mutations. Intense repetition of a specific motor task, such as playing a musical instrument or typing, can predispose individuals to focal dystonias, including writer’s cramp (Byl et al., 1996; Roze et al., 2009). In a review of 158 hemidystonia cases involving stroke, head trauma, or perinatal hypoxia as precipitating factors, 60% were found to have lesions in the contralateral striatum (Chuang et al., 2002). However, disruptions to the striatum, neocortex, GPi, VTA, thalamus, cerebellum, and brain stem can all produce forms of dystonia-like symptoms in animal models (Guehl et al., 2009). Dystonia is also associated with complications of childbirth (Bressman, 2000), presumably because of the hyper-sensitivity of the neonatal basal ganglia to hypoxia. The latency between the precipitating event and the onset of dystonia is often months to years, supporting the hypothesis that aberrant neuroplasticity in the striatum and/or neocortex contributes to dystonia (Byl et al., 1996; Quartarone et al., 2003; Peterson et al., 2010). Disorganization of the somatotopy in the somatosensory and motor cortices and in the basal ganglia has been observed in dystonia (Lenz et al., 1998; Vitek et al., 1999; Quartarone et al., 2008; Delmaire et al., 2009; Tamura et al., 2009). This may bear relevance to the fact that touching a body region near the affected muscle groups can sometimes alleviate symptoms – a long-recognized phenomenon referred to as a “sensory trick.”

Given the heterogeneity in the etiology of dystonia, it is to be expected that there are multiple cellular signaling abnormalities. However, there is a scarcity of reports on signaling mechanisms in dystonia, relative to the many such studies in models of PD, LID, and HD. Dopamine and acetylcholine signaling are known to be important in several forms of dystonia. The clearest example of this is dopamine-responsive dystonia (DRD; also known as Segawa’s disease or DYT5). DRD is an autosomal dominant genetic disorder that is usually produced by loss of function mutations in GTP cyclohydrolase 1 (GCH1; Ichinose et al., 1994; Ludecke et al., 1996; Thony and Blau, 1997, 2006). GCH1 is in the pathway for synthesis of tetrahydrobiopterin (BH₄), an essential cofactor for the dopamine-synthesizing protein, TH. Therefore, in DRD, there is likely a deficiency in dopamine, and related biogenic amines, throughout development. Age of onset is variable but often early, and symptoms range from focal to generalized dystonia to developmental delay (Segawa, 2011). Many of the symptoms are alleviated by l-DOPA administration, and LIDs are typically not a complication.

Loss of dopamine in adulthood is also associated with dystonia, as a secondary symptom of PD. In addition, the classical anti-psychotic medications that antagonize D2 receptor signaling precipitate acute or tardive dystonia in a significant proportion of patients and in animal models (Kiriakakis et al., 1998). Moderate abnormalities in D2 receptor binding and expression are observed in cases of focal and generalized dystonia (Tanabe et al., 2009), but whether the defects are in post-synaptic D2 receptors on MSNs, in presynaptic D2 autoreceptors that inhibit dopamine release or in D2-positive striatal interneurons remains controversial (Playford et al., 1993; Naumann et al., 1998; Napolitano et al., 2010).

Dopamine and acetylcholine signaling are tightly interrelated in the striatum and anticholinergic drugs improve dystonic symptoms in some patients and animal models (Bressman, 2000). Clues to the relevance of acetylcholine signaling in dystonia come from animal models of DYT1. DYT1 is produced by a mutation in torsinA (Ozelius et al., 1997), which is expressed widely but is enriched in the cholinergic interneurons of the striatum (thought to correspond mainly to the physiologically identified tonically active neurons, or TANs) and in dopaminergic neurons of the SNc (Shashidharan et al., 2000; Oberlin et al., 2004). D2 is expressed in cholinergic interneurons and can, under certain conditions, inhibit their activation and thereby permit long-term depression (LTD) in MSNs (Wang et al., 2006b). However, in slice recordings from the mouse model of DYT1, the effect is reversed such that D2 agonists activate cholinergic interneurons and MSNs fail to undergo LTD (Pisani et al., 2003). This failure of MSN neuroplasticity is rescued by blocking acetylcholine receptors. Thus, anticholinergics may serve to restore normal plasticity of MSNs in DYT1 models. Because cholinergic interneurons control striosome to matrix activity ratios (Saka et al., 2002), it is possible that anticholinergic therapies change the communication between these striatal compartments as well.

The most direct case made for a striosome to matrix imbalance in some types of dystonia comes from post-mortem analyses of striatal tissue from individuals with X-linked dystonia-parkinsonism (DYT3). DYT3 is caused by mutations in the transcription factor TAF1 and manifests as adult-onset dystonia, often generalized, that progresses to parkinsonism (Makino et al., 2007). Histological analyses of post-mortem striatal sections from five people with DYT3 who died during the dystonic phase and two people who died during the parkinsonian phase led to the discovery of severe striosome degeneration in the individuals with dystonia (Goto et al., 2005). Analyses suggested that gliosis and MSN loss is confined to the striosomal compartment in the individuals in the dystonic phase whereas MSN degeneration spreads to both compartments in the individuals in the parkinsonian phase of the disease. Striatal projections into the GPi, GPe, and substantia nigra all appear to be significantly depleted in a presented DYT3 case. TH staining for dopaminergic neurons in the substantia nigra was patchy, suggesting that there was also ventral midbrain pathology. Thus, DYT3 appears to cause degeneration of MSNs in the striosome compartment in the early phase of the disease and then progresses to cause degeneration of MSNs in the matrix compartment as well. This preferential loss of striosomal MSNs fits with the expression of N-TAF1, the neuron-specific isoform of TAF1 that is implicated as causative in DYT3. In the rat, N-TAF1 expression is strikingly enriched in striosomal MSNs, relative to the low expression in the extra-striosomal matrix (Sako et al., 2011).

Support for the possibility that striosomes are differentially affected in other forms of dystonia comes from a mouse model of an unusual form of DRD. To generate this mouse line, a mutation was introduced into 6-pyruvoyl tetrahydropterin synthase, an enzyme that is required for BH₄ synthesis and that was found to be mutated in a human case of DRD (Hanihara et al., 1997). These mutant mice exhibit abnormal hindlimb clasping and slow beam-crossing behavior, suggestive of dystonic and parkinsonian symptoms. A postnatal, striosome-predominant loss of TH protein is observed. The pattern of TH depletion also exhibits similarities to that observed in PD in that it was depleted in a caudal-to-rostral gradient and preserved in the nucleus accumbens (Sato et al., 2008). Unlike in PD however, this DRD mouse model shows preservation of SNc integrity, based on immunostaining of brain sections for markers of dopaminergic neurons. Thus, it appears that 6-pyruvoyl tetrahydropterin synthase is required for TH expression in the terminals of dopaminergic neurons targeting the striosomes, suggesting that preferential dopamine loss in the striosomes may occur in DRD. Clinical studies have yet to test this idea, however.

Drug addiction

Drug addiction is generally agreed to involve the repeated and escalating use of psychoactive drugs, despite adverse consequences such as loss of employment, friends, and family ties (Diagnostic and Statistical Manual of Mental Disorders IV). Only ∼15% of people and animals who experience a highly addictive drug escalate their use to the point of addiction (Deroche-Gamonet et al., 2004). Susceptibility to drug addiction has environmental components (in particular, repeated drug administration) and genetic components. Twin studies suggest that as much as 50% of the susceptibility may be genetic (Kreek et al., 2005). Relapse after withdrawal is associated, in both humans and animal models, with stress, re-exposure to the drug, or re-exposure to environmental cues associated with the drug (Sinha, 2008). Cues and experiences that promote reinstatement of drug use can activate the same brain regions as the drugs themselves, suggesting that they share neurocircuitry and underlying molecular mechanisms (Childress et al., 1999; Volkow et al., 2006).

It is widely agreed that there are differential effects of drugs of abuse on signaling pathways in the ventromedial and dorsolateral striatum, in the direct and indirect pathways, and in striosome and matrix compartments. Human brain imaging studies have shown that acute drug exposure activates limbic structures including the nucleus accumbens and amygdala and that repeated use expands the region of activation to include the dorsal striatum and neocortex (Breiter et al., 1997; Volkow et al., 2006; Porrino et al., 2007). This changing pattern of activation might be related to the change in self-reported effects of the drug: in the early phases, individuals describe hedonic effects of the drug but in late phases of addiction the effects are more likely to be described as “filling a hole” (Robinson and Berridge, 2008). This contrast fits with the notion that the ventromedial striatum and nucleus accumbens mediate goal-oriented behaviors (e.g., early, hedonia-seeking drug use) whereas the dorsolateral striatum and some neocortical regions mediate habitual behaviors (e.g., late, compulsive drug use; Yin et al., 2004; Barnes et al., 2005; Atallah et al., 2007). Considering that drugs of abuse and associated cues activate the dopamine system (Di Chiara and Imperato, 1988), the transition from ventral to dorsal striatum activity with repeated drug use may be influenced by indirectly recursive corticostriatal circuitry and an apparently progressive connectivity of the striatonigral loop (Haber et al., 2000; Ikemoto, 2007). This possibility has been supported by studies in rats in which physical disruption of this ventral to dorsal striatal connectivity pattern was shown to interfere with the development of habitual responding for drug access (Belin and Everitt, 2008). Thus, the development of a drug-taking habit may rely on the dorsal striatum, and other brain regions, that normally mediate the acquisition of motor and cognitive habits.

Locomotor and highly repetitive and idiosyncratic motor behaviors (stereotypies) are elicited in humans and animals under the influence psychomotor stimulants such as cocaine and amphetamine. These motoric responses to drugs of abuse escalate with repeated treatments, a phenomenon that is termed sensitization and that is thought to be related to drug addiction (Vezina and Leyton, 2009). There is strong evidence that both PKA and ERK1/2 cascades in MSNs mediate acute and sensitized responses to psychomotor stimulants (Ferguson and Robinson, 2004; Shi and Mcginty, 2006; Girault et al., 2007; Russo et al., 2010). Genetic deletion of DARPP-32 (a key effector of the PKA cascade) and inhibitors of MEK1 (an upstream activator of ERK1/2) each block sensitization to drugs of abuse (Valjent et al., 2005). Immunohistochemistry for phosphorylation of activating sites on various members of the PKA and ERK1/2 cascades show that drugs of abuse activate these cascades primarily in D1-expressing neurons (Valjent et al., 2005; Bertran-Gonzalez et al., 2008). Likewise, Delta FosB, an IEG that is downstream of both signaling cascades, is activated preferentially in D1-expressing neurons following drug treatments (Berretta et al., 1992; Hope et al., 1994; Moratalla et al., 1996; Zachariou et al., 2006; Fasano et al., 2009). Activation of D2-positive MSNs is not observed in most reports of MSN activation by drugs of abuse (Bertran-Gonzalez et al., 2008), but this finding may depend on the context in which the drug is taken, given that the activation of D2-positive MSNs is observed when drugs are administered in a novel cage (Badiani et al., 1999; Ferguson and Robinson, 2004; Vezina and Leyton, 2009). Furthermore, it is widely recognized that normal acute and sensitized responses to drugs of abuse are dependent on both D1- and D2-type dopamine receptor activation (Xu et al., 1994; Caine et al., 2002, 2007; Capper-Loup et al., 2002; Barrett et al., 2004; Bateup et al., 2010). Pharmacologic or genetic studies indicating a D2-dependence of drug responses do not typically specify the cell-type of action. Therefore, it may be that D2 activity is required in non-MSN cell types such as cholinergic interneurons, which are sparsely distributed in the striatum. Cholinergic interneurons are implicated in the development of LIDs (Ding et al., 2011) and are required for the increased striosome over matrix activity ratios associated with drugs of abuse (Saka et al., 2002). Psychomotor stimulants have also been shown to signal through D1/D2 heterodimers (Perreault et al., 2010). Thus, D2 expression in MSNs, striatal interneurons, dopamine-producing axon terminals, and D1/D2 heteromers may all be important for particular aspects of drug responsivity. Histochemical examination of post-mortem brains from cocaine addicts who tested positive for cocaine at autopsy, showed that mRNA for dynorphin was selectively elevated in striosomes in the caudate nucleus (Hurd and Herkenham, 1993). In animal models, strong behavioral responses to psychomotor stimulants, administered by intraperitoneal injection in the home cage, is correlated with a profound change in IEG induction in the striosome vs. matrix compartments, favoring increased activation in striosomes (Graybiel et al., 1990b; Canales and Graybiel, 2000; Vanderschuren et al., 2002; Glickstein and Schmauss, 2004; Saka et al., 2004). At very high doses, or with repeated treatments, psychomotor stimulants suppress locomotion in favor of a limited number of spatially confined stereotypies (Lyon and Robbins, 1975). In rats and monkeys, there is a direct correlation between the intensity of drug-induced stereotypy and the increased striosome to matrix ratio of IEG induction in the dorsolateral quadrant of the striatum (Canales and Graybiel, 2000; Saka et al., 2004). Based on this correlation, it was suggested that increased striosome activity and repressed matrix activity in this zone, together, could predict the degree of repetitive behavior expressed. The possibility that increased activity in the striosomes promotes stereotypies whereas activity in the matrix permits flexibility in motor behaviors is consistent with several additional studies. First, rats with a self-stimulation electrode implanted in or near a striosome learn to bar-press more frequently for stimulation than rats in which the stimulating electrode is implanted in the matrix (White and Hiroi, 1998). Second, metabolic labeling studies show that rats moving freely or under gentle restraint in their home cage have preferential activation of MSNs in the matrix compartment (Brown et al., 2002). Third, knockout mice that lack CalDAG-GEFI, an ERK1/2 regulator that is selectively enriched in the matrix compartment, show enhanced stereotypy responses to amphetamine, relative to sibling controls (Crittenden et al., 2006). Importantly, the CalDAG-GEFI knockout mice have normal locomotor responses to low doses of amphetamine, and locomote normally in the absence of drug, suggesting that disruption of matrix function specifically promotes stereotypies induced by high doses of amphetamine. The possibility that differential signaling in the striosomes vs. matrix is related to the switch from goal-oriented behavior to habitual, goal-independent behaviors that compare to drug-induced stereotypy is reviewed by Canales (2005).

Vanderschuren et al. (2002) showed that increased striosome to matrix activity was also observed in adult rats treated with a single high dose, or with repeated low doses, of amphetamine and suggested that the compartmental ratio change was correlated with overall drug response rather than specifically with stereotypies. However, this study did not rate stereotypic behaviors and even low doses of stimulant drug can induce intermittent stereotypies such as sniffing. A single high dose of methylphenidate, an indirect dopamine receptor agonist that is prescribed to children for ADHD, also induces preferential IEG expression in striosomes of adolescent mice (Davis and Puhl, 2011). In follow-up cell culture studies, methylphenidate appeared to be acting through D1 and cAMP-mediated signaling cascades, which are enriched in striosomes (Davis and Puhl, 2011). Likewise, in a study of spontaneous stereotypies in deer mice, it was found that there is an increase in direct over indirect pathway activity, relative to non-stereotypic controls (Tanimura et al., 2011). The stereotypic deer mice do not show changes in striosome to matrix activity, as measured by cytochrome oxidase histochemistry, however. Together, these studies indicate that an increased striosome to matrix activity ratio is correlated with hyper-responsivity to psychomotor stimulants.

Although one study found that deletion of a matrix-enriched signaling molecule (CalDAG-GEFI) is sufficient to promote drug-induced stereotypies (Crittenden et al., 2006), other studies show that an increase in striosome to matrix IEG activity is not necessary to elicit stereotypy. In rats, ablation of cholinergic and nitric oxide synthase-positive interneurons prevents the compartmentalized IEG induction ratio, but not the sensitization of drug-associated stereotypies (Saka et al., 2002). Additionally, mice lacking D2 show increased stereotypy responses to D1-type dopamine receptor agonists but do not exhibit increased striosome to matrix ratios of IEG induction (Glickstein and Schmauss, 2004). By contrast, mice with striosome, but not matrix, overexpression of the negative mGluR1/5 modulator, Homer1a, show enhanced locomotor and stereotypy responses to amphetamine (Tappe and Kuner, 2006). These mice may not have decreased mGluR1/5 signaling however, as they show strong and patchy (presumably striosomal) IEG induction in the striatum. Evidence that there is not a simple correlation between increased striosome function and increased responses to drugs of abuse comes from mice in which rostral striosomes fail to develop (Liao et al., 2008). Mice lacking RARβ, a transcription factor that is required for formation of rostral striosomes, exhibit enhanced repetitive behavioral responses to apomorphine. At a dose of apomorphine that does not affect behaviors of control mice, mice lacking RARβ show increased stereotypic responses. These results could be interpreted to indicate that increased striosome to matrix activity normally serves to dampen stereotypies. Alternatively, any striosome to matrix imbalance, regardless of direction, might predispose to drug-induced stereotypies. In addition, how the selective disruption of striosome or matrix function influences behavioral responses to drugs of abuse could depend on the context of drug exposure and which region of the striatum is activated. This apparent complexity is not surprising considering that different drugs of abuse induce distinct patterns of striosome and matrix IEG induction across the caudal–rostral and medial–lateral gradients of the striatum, and that there are differences in the connectivity and transmitter/modulator expression patterns of the striosomes themselves in different striatal regions (Graybiel et al., 1990b; Hurd and Herkenham, 1993; Wang et al., 1994; Tan et al., 2000; Adams et al., 2001).

Repeated treatment of rats with drugs of abuse also activates IEG expression in the cholinergic interneurons that reside at the compartment borders (Moratalla et al., 1996). This finding is likely related to the observation that prolonged l-DOPA treatment of PD models induces ERK activation in cholinergic interneurons (Ding et al., 2011). Moreover, pharmacological disruption of cholinergic signaling modulates stereotypy responses to drugs of abuse with a dependence on medial–lateral striatal gradients (Ohmori et al., 1995; Aliane et al., 2011). Ablation of cholinergic interneurons disrupts the increased striosome to matrix activity ratio in response to the direct dopamine receptor agonist, apomorphine (Saka et al., 2002). The CalDAG-GEFI knockout mice that have exaggerated drug-induced stereotypies have defective cholinergic signaling as well (Crittenden et al., 2006). Thus, cholinergic modulation of drug responses may occur, in part, through control of striosome to matrix activity ratios.

Studies in animal models suggest that the striosome and matrix compartments are differentially vulnerable to the loss of dopamine terminals that is caused by drug abuse. Treatment of mice with high doses of either methamphetamine or MDMA (“ecstasy”) causes selective degeneration of dopaminergic inputs to the striosomes, relative to the surrounding matrix (Granado et al., 2008, 2010). This selective vulnerability was suggested to be related to the relatively lower striosomal levels of superoxide dismutase 2 (SOD2; Zhang et al., 1994; Medina et al., 1996), which neutralizes the reactive oxygen species that are a byproduct of dopamine metabolism. Another possibility is that the enriched vascularization of striosomes (Breuer et al., 2005) causes them to have increased exposure to injected drugs. Striosomal immunomarkers are selectively depleted in rats treated with excitotoxic drugs or that undergo neonatal hypoxia (Burke and Baimbridge, 1993; Figueredo-Cardenas et al., 1998). The anti-apoptosis factor, Bcl-2, and the neurotrophic factor, GDNF, are enriched in striosomal neurons, suggesting that they may have compensatory anti-neurodegeneration mechanisms in place (Bernier and Parent, 1998; Lopez-Martin et al., 1999; Oo et al., 2005). There remain only a few cases in which brains of drug abusers were processed to detect striosomes, and cell death was not assayed in this study, but the selective striosomal enhancement of the opioid, dynorphin, could relate to striatum-based disruption of limbic-related behaviors in addition to effects attributable to the ventral striatum itself (Hurd and Herkenham, 1993).

In summary, normal and dopamine-depleted animals show a strong correlation between the degree of striosome to matrix ratio of MSN activation and the degree of behavioral response to dopamine agonists or drugs of abuse. New genetic tools that allow the specific activation or repression of genes in defined subsets of striosomal and matrix MSNs will allow us to better understand the meaning of this correlation.
