Big Data for Infectious Disease Surveillance and Modeling

Big Data in Support of Infectious Disease Surveillance

Infectious disease surveillance is one of the most exciting opportunities created by big data, because these novel data streams can improve timeliness, and spatial and temporal resolution, and provide access to “hidden” populations. These streams can also go beyond disease surveillance and provide information on behaviors and outcomes related to vaccine or drug use. However, the promise of these big-data streams must be balanced by caution.

In the first contribution, Simonsen et al [6] give a brief overview of the history of disease surveillance, highlight the gaps in current systems, and make the case for big data to strengthen and deepen syndromic surveillance. Using influenza as a case study, they demonstrate how the use of high-volume International Classification of Diseases–coded e-health medical claims data collected by large private-sector data warehouses sheds light on the spread of pandemics with unprecedented spatial detail. They highlight the gross underutilization of these data streams, due in part to privacy concerns and barriers in access to e-health data in academia and government. They also demonstrate how novel digital surveillance tools, such as Google Flu Trends [7], can go wrong because of overfitting and quickly go defunct. This issue is particularly salient after deep perturbations to disease dynamics, as is the case with the emergence of a new pandemic virus. Continued validation against traditional surveillance systems provides an hedge against these issues. In light of the rise and fall of systems based purely on digital search engine data, however, the way forward most likely involves “hybrid” systems that integrate digital big data with traditional laboratory-based surveillance and e-health data to improve the timeliness, accuracy, and depth of existing surveillance indicators.

In the next article, Guerrisi et al [8] discuss participatory surveillance, using the European influenza reporting system Influenzanet as an illustration. This surveillance system relies on volunteers signing up online to report their health on a weekly basis, in an effort to strengthen already well-established Sentinel physician-based systems in Europe. The authors highlight how such a system has the flexibility to be used for instant tracking of any emergent health problems. A key advantage of participatory systems is to report from populations who would not otherwise seek medical care for illnesses they perceive as minor, particularly adults with influenza-like illnesses. Furthermore, these systems allow for analysis of potential biases in the population sampled and the ad-hoc definition of cohorts of users specific to a particular health issue.

Next, MacFadden et al [9] address the seemingly unstoppable rise of antimicrobial resistance and the lack of a global monitoring of this issue in a timely manner. They introduce ResistanceOpen, a new online platform for monitoring of bacterial drug resistance, based on timely scanning, aggregation, analysis, and dissemination of local and regional online resistance index reports (http://www.healthmap.org/resistanceopen/). This approach is a direct extension of prior efforts to track infectious disease outbreaks globally by curating and analyzing a variety of online data sources (HealthMap [10]). Here, on-line resistance data compare favorably with traditional reporting systems in the United States and Canada so that ResistanceOpen offers a successful platform for sharing antibiotic resistance prevalence for multiple pathogens on local scales.

In the next paper, Salathe [11] sees big data as a creative solution for improving detection of drug adverse events in the future, relying on patients researching information online or reporting their postexposure symptoms in health forums, on Twitter or Facebook. Statistical mining of unstructured texts derived from these data streams could uncover associations between adverse events and specific drugs, and greatly improve the timeliness of surveillance in this area. A similar argument could be made for tracking of vaccine-related adverse events, which currently rely on passive reporting by physicians. Analysis of internet and social media data streams could complement the Food and Drug Administration's Sentinel initiative, a recent effort to identify drug-related adverse events in large e-patient individual databases. Importantly, public-generated digital data can also be mined for information on behavior and sentiments, so as to monitor vaccine hesitancy and drug uptake [12, 13]. An important challenge here is to find balance between the timeliness of social media information and the cost of unfounded alerts. Indeed, claims of adverse events can quickly and irreparably taint lifesaving drugs or vaccines in the public opinion. As with disease surveillance, building hybrid systems that integrate big-data streams with passive physician reports of adverse events will help safeguard the accuracy and specificity of the alerts.

Beyond Surveillance: Big Data for Modeling of Disease Transmission Dynamics and Control

The wealth of information promised by big data, combined with the development of new analytical and modeling tools, will help shed light on intricate details of the transmission dynamics of infectious diseases that have so far remained obscured by lack of granular data. Four articles in this issue tackle this topic.

In the first article touching on modeling, Moran et al [14] reflect on the state of the art of epidemiological modeling and judge it to be on par with that of particle physics in the 1970s. They argue that epidemic modeling of nonhealth data, such as Internet search queries, is an example of rising to the challenge of catching up this delayed development. They draw an interesting parallel between disease forecasting, which remains in its infancy, and weather forecasting, which is deemed the reference standard for real-time integration and modeling of large data streams, followed by immediate release of personalized outputs—as attested by the omnipresence of forecasts in the media, the Internet, and smartphones. Improvement in disease forecasts will require a large increase in the volume of epidemiological information available for modeling, which big data may deliver, but will also require better standardization of disease reports and case definitions across time and space. The authors also note that communication of forecast uncertainty is a challenge and typically better accomplished in meteorology than disease forecasts - everyone understands a 20% chance of rain but not a 20% chance of outbreak. Finally, although weather forecasts are ultimately driven by the inalterable laws of physics, changes in human behavior (eg, due to risk perception and media attention) can affect the dynamics of an outbreak and skew its associated digital footprints, making disease forecasts potentially more complex.

Next, Lee et al [15] review the technical, practical, and ethical challenges of using big data to understand the spatial distribution and transmission of infectious diseases. The heterogeneity of data sets and data types particular to this field makes integration of different data streams obtained at different spatial scales technically challenging; greater use of multilevel Bayesian statistical approaches would help alleviate this issue. The authors also stress a conceptual chasm between classic epidemiology and the world of big data, related to the notion of sampling. Indeed, there is a lack of effort to conduct proper sampling and address issues of representativeness and coverage in big data, in contrast to the long history of developing sampling theories centered on formulation of well-specified hypotheses in classic epidemiology. Finally there are privacy issues associated with analysis of ever more detailed spatial data. Creative solutions include simulation of synthetic data sets reproducing the key epidemiological features identified in big data, while ensuring confidentiality of individual cases.

In the next article, Wesolowski et al [16] see great potential in global positioning system information gleaned from cell-phone data and satellite imagery to inform population movements and network interactions, which drive the dissemination of epidemic diseases. They note that cell-phone usage remains heterogeneous in developing countries but is rapidly increasing. Notable biases in cell-phone data include, call frequency, tower density, ownership, and coverage, which is typically affected by socioeconomic status, age, and urban/rural residence. Some level of data aggregation can generally solve these biases, although identifying the right scale appropriate for disease transmission remains an issue. Research directly connecting cell-phone movements and disease data is in its early phase, but 2 successful examples are worth noting, both set in Kenya. These include studies of how population movements can help dissect the source-sink spatial dynamics of malaria and how seasonal fluctuations in travel drive rubella epidemics. Looking to the future, cell-phone data will probably be more useful for modeling invasion waves of new pathogens rather than well-established pathogens, and further research should focus on careful cross-pathogen comparisons.

Next, Chowell et al [17] propose using Internet news reports and health bulletins to compile information on clusters of patients, and infer transmission trees and reproduction numbers, using lessons drawn from work on Middle East respiratory syndrome and Ebola virus outbreaks. Sourcing news media data can yield rapid and accurate assessment of transmission chains, which is crucial in the absence of detailed surveillance data, as was the case for much of the 2014 Ebola epidemic. Although Chowell et al used a manual approach to search, identify, extract, and model relevant information, they point out that this approach could be expanded with automatic scans of all Internet news and development of language processing tools to identify sequential transmission events. This approach, based on methods developed by HealthMap [10] and other Internet-based surveillance resources, could provide a particularly productive avenue for surveillance in low- and middle-income countries, where detailed transmission studies are scarce, and in infectious disease crises settings when time is of the essence.

Finally, Liu et al [18] introduce a novel system for data management and epidemic simulation, analysis and visualization, EpiDMS. This tool aims to fill an important gap in decision making during healthcare emergencies by generating near-real-time projections and simulations of an emerging pandemic trajectory. Arguably, models can be sensitive to parameters, and many rounds of simulations should be performed to address uncertainty and explore different epidemiological scenarios. EpiDMS provides an interface to facilitate interpretation and visualization of large numbers of multivariate simulations. For instance, this tool would allow public health experts to identify a set of conditions (eg, thresholds of vaccine coverage and effectiveness) that are consistent with a given epidemic trajectory (eg, a decline of 50% in transmission). Such simulation tools can provide crucial actionable data for public health experts and modelers.

Validation and Integration With Existing Systems

A key requirement of any new system, whether it involves big data or not, is a careful and continued validation against established systems. As we have seen with Google Flu Trends, an initial honeymoon period when the tool appeared accurate was overshadowed by failures to detect unusual patterns, such as the emergence of a pandemic. Similarly, the sensitivity of big-data surveillance for adverse events should be tested against known associations, such as the increase in infant intussusception linked with the Rotashield rotavirus vaccine, Guillain-Barré syndrome and pandemic influenza vaccines, or anemia with certain cancer drugs. In the absence of a reference standard for surveillance, as may be the case in developing countries, one could validate two or more big-data indicators against each other. Further, specificity has to remain high, so as not to overload the public health infrastructure with useless outbreak alerts, and in the case of adverse events, to prevent public mistrust and waste of perfectly safe drugs or vaccines. Hybrid systems can help overcome this issue in part, because they are validated in an ongoing fashion against traditional data. Intelligent integration of disparate sources of data in useful hybrid systems will also require further methodological developments, in particular around “data synthesis” approaches [19, 20].

Representativeness and Biases

A few shortcomings specific to digital data are worth keeping in mind. Many of these data streams lack demographic information, such as age and sex, which is an important component of almost any epidemiological study. Furthermore, they represent an ever-increasing but still limited segment of the population, with lack of coverage among infants, and fewer elderly than younger individuals represented. There is geographic heterogeneity in coverage, with underrepresentation in developing countries, though these biases tend to disappear and are arguably less pronounced than those found in traditional surveillance systems on a global scale. Furthermore, there is spatial and temporal uncertainty in the information retrieved; for instance, a young man in New York may be researching his grandmother's illness that occurred in Florida 3 weeks earlier. In addition, tools of big data are blind to important animal epidemics and zoonotic diseases at the human-animal interface. Here, “hybrid” systems could be created to combine digital data with veterinary or agricultural reports on recent animal disease outbreaks.

Data Volatility

As often with new technologies and innovation, digital data streams are not always continuous but rather subject to user interest, popularity, and financial concerns. Whereas laboratory-based surveillance for influenza has existed at the Centers for Disease Control and Prevention for >40 years in a continuous form, Google Flu Trends lasted less than a decade. This issue is compounded by the fact that digital data streams are not specifically created for surveillance or research purposes, and there is no incentive to maintain these tools once they go out of fashion.

Use of Data: Managing Signal Versus Noise and Experimental Approaches

Perhaps the most intriguing question is how the public health community will use this anticipated overload of data. Big data are generally unstructured, biased, and noisy; replicability and transparency must be at the center of data science. Users of big data must stay away from the pitfalls of “big data hubris” [21] and complement novel approaches with rigorous statistical and hypothesis-driven analyses. Conversely, a substantial advantage of social media over observational surveillance is the possibility to conduct experiments, for instance, to study contagion phenomenons (see the “viral” diffusion of online petitions [22]), which is akin to experimental epidemiology.

Data Volume and Forecasting Horizon

Although computational approaches are increasingly used for public health planning, contingency plans preparations, and near-real-time forecasts at time of infectious disease crisis, the field is certainly far from the consolidated state of the art we find in other scientific disciplines such as weather forecasting. The ongoing big data revolution should remedy the sparseness of existing epidemiological observations, so that accurate forecasts of disease trajectories several weeks ahead will become feasible on a local scale [20]. The last 10 years have seen dramatic advances in data collection and digitalization, finally allowing the construction of a portfolio of data-driven epidemiological models. The increasing number of available models and the lack of best practices in integration and data sharing are however major roadblocks in the development of the field. Meanwhile, predicting the emergence of new infectious diseases, is a much more complex goal and will require further research on disease dynamics in zoonotic reservoirs, human-animal contacts, and host species barriers, which go well beyond big data [23].

In conclusion, this supplement offers a cautiously optimistic view of the progress of big data for infectious diseases surveillance and control during the last decade. We hope this collection of articles will spark dialogue and collaborations between the public health community, epidemiologists, big data specialists, physicists, and disease modelers alike. Multi-disciplinary initiatives such as the Big Data To Knowledge (BD2K) program led by the National Institutes of Health will be instrumental to strengthen funding and use of big data in biomedical research [24]. Aided by these large programs, further research will need to resolve some of the issues and gaps identified here and realize the full potential of big data for infectious disease control. Those in the field of disease surveillance and modeling can learn a lot from other data-and modeling-hungry fields, such as meteorology and marketing, and can ultimately provide useful tools to improve situational awareness and outbreak response for a variety of old and new infections.
